Page 18 - spindle22

SPINDLE TOOLING Quality products - quality service

Alloy steel (SP) profile knives Profiles are shown full size
(50x4mm) from the back of the knife

Profile knives, limitors & blanks – 50mm x 4mm range

A range of 50mm wide SP alloy steel profile knives, limitors and blanks. These profile
knives have the same locator pin spacing as the 40mm wide (6mm pins on 24mm
centres) and will fit the 40/50mm blocks F221140 and F221143 listed on page 2.
ORDERING INFORMATION: Order using the part numbers shown against the profile
knife illustrations on the following pages. For the matching limitors, replace the “131” in
the part number with “132” (e.g. limitors part number for profile F131020 is F132020).
N.B. Kn = knife part number & Li = limitor part number.
SP grade steel profile knives are suitable for cutting soft and hard woods but are NOT suitable for
man made boards e.g. MDF.
PRICES for knives, limitors and blanks are per pair.

Blanks

Part number Description
F131194 Blank -SP (34mm)
F131195 Blank - HSS
F132194 Limitor for blank

Alloy Steel (SP) Profile Knives (50mm) Limitor Plates (50mm)

Part number Description Pages Part number Description Pages
F131000 – F131024 Profiles 000 – 024 16 – 19 F132000 – F132024 Limitors 000 – 024 16 – 19
F131041 – F131080 Profiles 041 & 080 19 – 23 F132041 – F132080 Limitors 041 – 080 19 – 23

Alloy steel (SP) profile knives Profiles are shown full size
(50x4mm)

000 001 002

Kn F131000 Kn F131001 Kn F131002
Li F132000 Li F132001 Li F132002
