MINI MOULD

This new and unique system allows you to use your router and table as a miniature spindle
moulder. Various arbor and cutter head combinations are available to enable the production
of mouldings with one or more passes. With the short arbors and a guide bearing the cutters
may be used free hand or with the longer arbors they can be used in a
table. The longest arbors enable mouldings to be run in the middle of
boards up to 150mm wide. Suitable for edge moulding boards and
producing a wide range of mouldings for use in furniture restoration etc.

ARBORS FOR MINI MOULD
Replacement parts
A range of arbors to suit the MINI MOULD cutters. They are
available in 8mm, 3/8" and 1/2" shank sizes however the Part No. Description
longest arbors for use in tables are only in 1/2" shank.
TS5600 set of spacers
N.B. The arbor is supplied complete with spacers.

Part No. A B C D BEARINGS for MINI MOULD
T3401 – 8 8mm 38mm 8mm 45mm Bearing Diameter
T3405 – 8 8mm 40mm 8mm 70mm
TB908 19.0mm
T3402 3/8 8mm 38mm 3/8 45mm
TB910 22.0mm
T3403 1/2 8mm 38mm 1/2 45mm
TB912 24.0mm
T3404 1/2 8mm 40mm 1/2 70mm TB913 26.0mm
T3406 1/2 8mm 40mm 1/2 100mm TB915 28.0mm

MINI MOULD CUTTER HEADS
These cutter heads are for use with the Mini Mould arbors above. They can be used with or without
bearings. The bearing listed against each cutter gives the optimum depth of cut on all cutters except
Vee types where it gives the maximum cut depth. Other bearings are available to alter the cutting depth.
Bead mould

Part No. A B C D E bearing

T3413 1.5mm 4.0mm 8mm 29.5mm TB913
T3414 1.75mm 4.5mm 8mm 30.0mm TB913
T3415 2.0mm 6.0mm 8mm 30.5mm TB913
T3417 3.0mm 7.8mm 8mm 32.5mm TB913
T3418 4.0mm 10.2mm 8mm 34.5mm TB913
T3419 5.0mm 12.4mm 8mm 36.5mm TB913

Vee 90

Part No. A B C D E bearing
T3430 17.5mm 9.0mm 8mm 34.2mm TB908

Vee 60
Part No. A B C D E bearing
T3432 11.0mm 9.0mm 8mm 37.5mm TB908

Vee 45

Part No. A B C D E bearing
T3434 8.0mm 9.5mm 8mm 38.0mm TB908
