Page 34 - Router Catalogue 2021

WEALDEN TOOL
TCT ROUTER BITS Quality products - quality service
COM PAN Y

MORTAR GROOVE – CHAMFER

This range of two flute cutters is suitable for producing mortar grooves and
chamfers and, in addition, has the option of fitting a bearing kit to increase the
cutters’ versatility.

Part No. A B C D E F°
T1908 1/2 42mm 20mm 1/2 38mm 12mm 30°
T1910 1/2 42mm 22mm 1/2 38mm 12mm 45°
T1912 1/2 38mm 26mm 1/2 38mm 12mm 60°

Guide bearing kit
(order separately)

Part No.
TB1910
Profiles are shown approximately full size

T1908½ T1910½ T1912½

Bearing kit TB1910
(order separately)

DOWN CUT SHEAR MULTI TRIMMER

This adaptable double bearing guided cutter has two down-shear cutting blades
which ensure a clean cut even in difficult materials. In addition, the positive shear
angle reduces breakout on the top edge, making it ideal for trimming veneered board.
The two bearing design allows the cutter to be used with the template mounted on
either side of the work and, consequently, it is possible to cut from either direction
using only one template and without moving the template to the other side of the
workpiece. This is especially useful when cutting curves which run both with and
against the grain.

Part No. A B C D
T8175B 1/2 19.0mm 50mm 1/2 50mm

Replacement parts

Part No. Description
TC002 Shaft collar
TB575 Shaft bearing
TB748 Bottom bearing
TS1603 Shaft dust shield
TS3900 Bottom dust shield

Orderline 01580 890500 32 Fax orders 01580 890222
