MULTI BORING DOWEL DRILLS

A range of multi-boring dowel drills, available in Left Hand and Right Hand rotation, suitable for use
in single and multi-head boring machines. The tools have a 10mm shank which incorporates a flat for
secure location and a grub screw in the shank end for precise height adjustment. Solid Tungsten
Carbide tips make the drills suitable for use in solid timbers and man-made boards. Two point types
are available: lip & spur for blind hole and 60° V point for through hole drilling.

TCT dowel drills 60° V point 70mm – shank Ø10mm x30mm
Part No. A B C D
diameter drill length shank overall
RH LH mm inch mm mm mm
DV70040R DV70040L 4.0 35 10 70
DV70050R DV70050L 5.0 35 10 70
DV70060R DV70060L 6.0 35 10 70
DV70075R DV70075L 7.5 35 10 70
DV70100R DV70100L 10.0 35 10 70
DV70120R DV70120L 12.0 35 10 70

MULTICUT – TCT DRILL SET

These tungsten carbide tipped drills are specially ground to enable the precision drilling of
materials such as tiles, natural stone, metal, wood and plastics. They are particularly useful when
fixing battens etc. where the timber and walls can be drilled without having to change drill bits.

TCT multicut drill set

Part No. drill diameters in set

DMC410 4mm 5mm 6mm 8mm 10mm

HSS–COBALT JOBBER DRILL SETS

Cobalt alloyed jobber drills with high heat resistance suitable for
drilling most materials including high alloyed steels and stainless
steel. These drills are manufactured to DIN338RN in bright
finish with 130 degree cross cut point.

HSS–cobalt drill sets 130 V point
Part No. set contents

DHC06 6 pcs. (2, 3, 4, 5, 6 and 8mm) in plastic pack
DHC19 19 pcs. (1.0 – 10.0mm in 0.5mm steps)
DHC25 25 pcs. (1.0 – 13.0mm in 0.5mm steps)
