CAPILLARY GROOVE

Two types of cutters for
forming rebates and capillary
grooves for window frames,
sills etc. The cutters form a
rebate at either 90° or with a
4° taper.

Part No. A B C D E°

T2350 – 8 3.0mm 28mm 8mm 32mm 90°
T2351 1/2 3.0mm 28mm 1/2 38mm 90°
T2352 – 8 3.0mm 28mm 8mm 32mm 86°
T2353 1/2 3.0mm 28mm 1/2 38mm 86°

DRAWER PULL – SMALL

This two flute cutter will produce the enclosed slot
type finger grip. It is necessary to cut an initial
groove with a straight 2 flute cutter of at least
19mm diameter and then make two passes with
the drawer pull cutter to obtain the desired width.

Part No. A B C D E
T7110 19mm 13mm 1/4 38mm 4.0mm
T7111 – 8 19mm 13mm 8mm 38mm 4.0mm
T7112 1/2 19mm 13mm 1/2 40mm 4.0mm

DRAWER PULL

Two larger sizes of drawer pull cutters.
They are commonly used to produce
finger grip profiles in drawers and kitchen
cabinet doors. They are usually used to
cut grips in solid timber door trims etc. but
may also be used in MDF.

See also Ovolo scribe cutters on page 53, which may also be used for finger pulls.

Part No. A B C D E F G
T7122 – 8 38mm 19.6mm 8mm 38mm 6.3mm 2.4mm 18.0mm
T7123 1/2 38mm 19.6mm 1/2 40mm 6.3mm 2.4mm 18.0mm
T7127 1/2 48mm 14.5mm 1/2 40mm 4.0mm 2.0mm 13.5mm
