ESPAGNOLETTE GROOVE CUTTER – 16mm

These tungsten carbide
tipped eurogroove cutters
will cut grooves for 16mm
wide espagnolette locking
systems. They have a
shank mounted bearing
enabling them to cut
rebated door sets.

Replacement parts
Part No. Description
Part No. A B C D T5931 Cutter head

T5930 – 8 44mm 16.2mm 8mm 55mm T3052 Arbor
T5930 3/8 44mm 16.2mm 3/8 55mm TB960 Bearing
T5930 1/2 44mm 16.2mm 1/2 80mm TS5790 Dust shield

ESPAGNOLETTE GROOVE CUTTER – 20mm

These tungsten carbide
tipped eurogroove
cutters will cut grooves
for 20mm wide
espagnolette locking
systems. They have a
shank mounted bearing
enabling them to cut Replacement parts
rebated door sets.
Part No. Description
Part No. A B C D T5933 Cutter head

T5935 – 8 44mm 20.5mm 8mm 55mm T3052 Arbor
T5935 3/8 44mm 20.5mm 3/8 55mm TB960 Bearing
T5935 1/2 44mm 20.5mm 1/2 80mm TS57900 Dust shield

ESPAGNOLETTE GROOVE VERTICAL

A cutter to cut the faceplate rebate
and clearance for the mechanism for a
16mm nominal espagnollete locking
system. This type of cutter will profile
vertically when the traditional
horizontal cutter can not be used.

Part No. A B C D E F
T4420–8 16.2mm 10mm 8mm 38mm 12.0mm 10mm
T4420 1/2 16.2mm 10mm 1/2" 40mm 12.0mm 10mm
T4425 1/2 20.5mm 12mm 1/2" 40mm 14.2mm 9.2mm
