Page 18 - CNC catalogue 2021

STC ROUTER CUTTERS

Acrylic Spiral Flute Up Cut - STC

A range of helical fluted up-cut solid tungsten carbide cutters specially Ød
ground for cutting acrylic. The polished flute design allows for smooth feed
rate, efficient chip clearance and a cleaner finish.

Single flute solid carbide cutters offer fast cutting and are especially suited
to cutting low melting point plastics. The design of two flute cutters gives
reduced contact with the material, plus gradual lead-in when first cutting
and is the perfect preparation before flame polishing of Perspex.

OL
Part
Number ØD mm ØD inch C1 Ød OL Flutes
T4AU300AZ2 3.00 0.118 12mm 1/4 65mm 2
T4AU400AZ2 4.00 5/32 14mm 1/4 65mm 2
C1
T4AU600BZ2 6.00 15/64 19mm 1/4 65mm 2
T4AU630AZ1 6.35 1/4 10mm 1/4 65mm 1
T4AU630BZ1 6.35 1/4 20mm 1/4 65mm 1
ØD
T8AU400AZ2 4.00 5/32 14mm 8mm 80mm 2
T8AU600BZ2 6.00 15/64 19mm 8mm 80mm 2
T8AU800BZ2 8.00 5/16 25mm 8mm 80mm 2
T8AU800CZ1 8.00 5/16 30mm 8mm 80mm 1

Ød = shank diameter
ØD = cutting diameter
OL = overall length
C1 = blade length
