Page 111 - Router Catalogue 2021

WEALDEN TOOL
DRILLING TOOLING Quality products - quality service
COM PAN Y

HINGE BORING BITS

A range of boring cutters to suit the popular sizes of concealed cabinet hinges
and KD fittings. All sizes have a centre point and two scoring cutters and
produce a clean flat bottomed hole in all timbers and particle boards. Cutters up
to 26mm diameter may be used at speeds up to 25,000 rpm, however the larger
cutters should ideally be used at speeds below 10,000 rpm in a pillar drill or
similar, although a variable speed routing machine is also suitable. The TD1835
is for use in multi-boring machines and has a flatted shank and height
adjustment screw. In addition to hinge sinking, these cutters are also ideal for
any operation requiring a clean bored hole with a flat bottom.

Part No. A B C D
T1815 – 8 15.0mm 26mm 8mm 38mm
T1820 – 8 20.0mm 26mm 8mm 38mm
T1820 20.0mm 26mm 3/8 38mm
T1822 22.0mm 26mm 3/8 38mm
T1825 25.0mm 26mm 3/8 38mm
T1826 26.0mm 26mm 3/8 38mm
T1830 30.0mm 28mm 3/8 38mm
T1835 – 8 35.0mm 28mm 8mm 38mm
T1835 35.0mm 28mm 3/8 38mm
TD1835 35.0mm 30mm 10mm 38mm
T1835A 35.0mm 28mm 1/2 40mm
T1840 40.0mm 28mm 1/2 40mm
T1850 50.0mm 28mm 1/2 40mm

ADJUSTABLE BORING BIT

This single heavy duty TC tipped cutting edges for effortless
cutter saves the cost of a cutting in all materials
whole range of boring bits.
Two adjustable cutting blades
Useful for those supplied to cover hole sizes from
in-between sizes that are 24mm to 50mm
difficult or impossible to Produces an extremely clean cut
get. hole even in difficult materials
Produces clean accurate Heavy duty construction - suitable
holes in all natural and for production work
man-made timbers.
For use in boring machines, drills in
drill stands, drill presses etc.

Part No. A B C D
D100 25 – 50mm 95mm 3/8 58mm

Replacement parts
Part No. Description
D100SB Replacement small blade WARNING – THIS CUTTER IS NOT SUITABLE FOR USE IN ROUTING
D100LB Replacement large blade
MACHINES OR HAND HELD DRILLS. MAXIMUM SPEED 2,000 rpm.
