Page 61 - Router Catalogue 2021

WEALDEN TOOL
TCT ROUTER BITS Quality products - quality service
COM PAN Y

SASH BAR OVOLO

A two flute cutter to produce the traditional glazing bar profile for producing window and
door frames etc. This cutter may be fitted with guide bearings (order separately) to
produce either a round over or quirk, as specified by dimension ‘H’ below. These cutters
may be paired with the sash bar scribe cutters to produce matching joints for ease of
frame assembly.
The T1350 cutter matches T1355 and the T1360 matches T1365.

Part No. A B C D E F G
T1350 22mm 9mm 1/4 38mm 5mm 6.3mm 4.7mm
T1360 25mm 12mm 1/4 38mm 6mm 10.0mm 6.0mm
T1360 1/2 25mm 12mm 1/2 40mm 6mm 10.0mm 6.0mm

Guide bearing kits
(order separately)

Part No. H
TB1300A 0
TB1300B 1.3mm
TB1300C 2.3mm

SASH BAR SCRIBE

This cutter produces a matching scribed
profile to mate with the sash bar ovolo cutters
T1350/T1360. This method of jointing allows
for the rapid construction of windows, doors
etc. with traditional glazing bar profile.
When producing scribed joints it is important
to use a router table or similar so that the end
of the rail to be scribed can be presented
square to the cutter.

Part No. A B C D E F
T1355 25.4mm 9mm 1/4 38mm 5mm 6.3mm
T1365 28.0mm 12mm 1/4 38mm 6mm 10.0mm
T1365 1/2 28.0mm 12mm 1/2 40mm 6mm 10.0mm

SURFACE TRIM

A three flute cutter for surface machining and
clearing large areas when carving etc. This cutter
is also suitable for many other uses, including
trimming timber edge banding.

Part No. A B C D

T2410 25mm 13mm 1/4 38mm
T2420 1/2 50mm 16mm 1/2 40mm

Orderline 01580 890500 59 Fax orders 01580 890222
