Rebate blocks with TC disposable inserts

Replaceable tip cutter heads for rebating in softwoods, hardwoods and all man-made
boards. Heads are manufactured in steel and all have 2 cutting flutes and 4 scribes.
The easily replaceable tips ensure consistent performance and fast set up.
Manufactured to EN847-1/2 - suitable for HAND FEEDING.

Part Size Body Maximum Maximum
number dia. height bore material rebate depth RPM
F252100 100 30 30 Steel 20mm 13,300

F252150 100 50 30 Steel 20mm 13,300
F252170 125 50 30 Steel 30mm 13,300
F252173 125 50 1¼” Steel 30mm 13,300

Shear rebate blocks with TC disposable inserts

Replaceable tip cutter heads for rebating in softwoods, hardwoods and all
man-made boards.
Heads are available in steel and all have 4 tungsten scribes and 4 tungsten
knives. The easily replaceable tips ensure consistent performance and fast
set up. Shear angle cutting reduces tear out and improves the quality of cut.
Manufactured to EN847-1/2 - suitable for HAND FEEDING.

Part Size Body Maximum Maximum Knives
number dia. height bore material rebate depth RPM

F253320 125 50 30 Steel 26mm 9,000 4 + 4
F253130 125 60 30 Steel 27mm 10,300 4 + 4
F253350 150 60 30 Steel 40mm 9,000 4 + 4
F253353 150 60 1¼” Steel 40mm 9,000 4 + 4

Replacement tungsten carbide knives and scribes

Replacement TC knives and scribes for use with blocks listed on this page.
N.B. All blocks are supplied fitted with one set of knives and scribes. F253130
All TC knives are priced and sold singly.
Part Knife size (mm) For use with
number
F001030 30 12 1.5 F252100
F001050 50 12 1.5 50mm height blocks

F001060 60 12 1.5 60mm height blocks
F001014 14 14 2.0 Scribe for all blocks
