CNC ROUTER CUTTERS
Ball Nose Roughing Swop-tip©
A cutter for deep roughing with a radius on the bottom of the
cut. Useful for 3D contouring where deep cuts are required.
Swop-tip© disposable insert ball nose profile cutter with 12 roughing
knives. These cutters offer the benefit of constant geometry and easy tip
replacement.
Part
Number ØD Ød R L1 OL
NA1932015 30.0mm 20mm 15mm 85mm 130mm
Spare
Parts Description Size
TK12 TC knife 12 x 12 x 1.5 – quantity 1
TK12B TC knife 12 x 12 x 1.5 – quantity 10
NA1931014 Radius knife R = 15mm – quantity 1
TQ405 Clamp screw M4 x 5 (8mm head) – quantity 1
KT15 Torx key T15
Ød = shank diameter
ØD = overall diameter
R = radius of cutter
L1 = cut length
OL = overall length
