SPINDLE TOOLING Quality products - quality service

Glue finger jointing blocks with TC disposable inserts

A two wing cutter block with easily replaceable TC inserts. The
replaceable tips ensure consistent cutting performance with no
sharpening necessary: simply replace the inserts when they
become blunt. Suitable for producing “finger style” reversible
glue joints in softwood, hardwood, plywood and all man made
boards. Supplied with two TC knives.
STOCK THICKNESS RANGE: 28mm – 58mm
Recommended speed range 5,900-9,000 RPM.
Manufactured to EN847-1/2 - suitable for HAND FEEDING.

Part Size Body Maximum
number dia. height bore material RPM

F272360 140 60 30 Steel 9,000

Blades and spare parts
Priced and sold singly.

Part Description
number
F001860 TC blade 60mm - 3 finger
F002055 Clamp screw M6 x 16

Sanding drum

A compact sanding drum for use on a spindle moulder.
N.B. For right hand (clockwise) rotation only.
These drums use sheet abrasive which is held securely with a
firm clamping action. Takes 80mm wide abrasive paper.

Part Size Maximum Body Maximum
number dia. height bore paper width material RPM

F259590 45 100 30 80mm Alloy 4,500
F259600 60 100 30 80mm Alloy 4,500
F259603 60 100 1¼” 80mm Alloy 4,500

F259800 80 100 30 80mm Alloy 4,500
F259803 80 100 1¼” 80mm Alloy 4,500

Sanding roll

Part number Description
JD50080080 50m roll x 80mm wide - 80 grit

42 Orders 01580 890500 Technical 01580 890500 Fax 01580 898222
